Raspberry Pi 3 Model A+


In stock

This board is the latest revision of the Raspberry Pi board, packing the same punch as the Raspberry Pi 3 B , on a smaller footprint. For the first time ever, this Model A board also has the beefy WiFi chip from the Model B . This is the perfect board if you’re looking for the power of the B with less power usage.

  • The Brains – 64-bit SOC @ 1.4GHz – Using the same Broadcomm BCM2837B0 as it’s brother board, the processor is a tried and tested option for maker projects.
  • The Memory – 512MB LPDDR2 SDRAM – A slight downgrade from the B , 512MB is more than enough for most projects.
  • Connectivity – 2.4 GHz and 5 GHz WiFi & Bluetooth – Using the same specs as it’s brother board, the A comes with 802.11.b/g/n/ac AND Bluetooth 4.2/BLE. That means your IoT projects can be tackled with this board.
  • Interfacing with Maker Gear – 40 Pin GPIO – The GPIO is the same as all of the Pi’s before it, meaning HATs, Pinouts and Adapter Plates all work the same way with the A
  • Seeing and Hearing the Pi – HDMI, DSI, CSI, 4 Pole Stereo and Composite Video – With HDMI you can connect right up to any modern screen, the DSI connector is great for using Maker displays, the CSI connector allows you to hook a camera right into the Pi, and there’s more by way of composite video. You’ll be seeing your Pi desktop with ease.
  • Power: 5.1VDC via micro-b USB

AUD$ 49.99

In stock

Technical Specifications

  • Processor: Broadcom BCM2837B0, Cortex-A53 64-bit SoC @ 1.4 GHz
  • Memory: 512MB LPDDR2 SDRAM
  • Connectivity: 2.4 GHz and 5 GHz IEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2/BLE
  • Access: Extended 40-pin GPIO header
  • Video & sound: 1 × full size HDMI, MIPI DSI display port, MIPI CSI camera port, 4 pole stereo output and composite video port
  • Multimedia: H.264, MPEG-4 decode (1080p30);  H.264 encode (1080p30); OpenGL ES 1.1, 2.0 graphics
  • SD card support: Micro SD format for loading operating system and data storage
  • Input power: 5.1V DC via micro USB connector, or 5V DC via GPIO header
  • Environment: Operating temperature, 0–50°C
  • Production lifetime: The Raspberry Pi 3 Model A will remain in production until at least January 2023
  • Dimensions: 55mm x 65mm , if you need more look at the product brief below for full technical drawings.
SKU: RK0062 Category: Brand:
Weight 0.5 kg
Dimensions 22 × 16 × 8 cm
